The WAGO 2022-108 1-Conductor Female Connector is a compact, pluggable terminal block designed for fast, tool-free wiring. It features WAGO’s Push-in CAGE CLAMP® technology, allowing direct insertion of solid and ferruled conductors without preparation. This 8-pole connector supports conductor sizes from 0.25 mm² to 4 mm² and is rated for up to 690 V and 24 A.
With a pin spacing of 5.2 mm and a gray polyamide housing, the 2022-108 is ideal for dense wiring environments. It’s part of the X-COM® S system, offering modularity and flexibility for control cabinets, switchgear, and automation systems. The front-entry wiring design simplifies installation and saves time during assembly.
This connector is flame-retardant (UL94 V-0) and built for long-term durability. It’s especially useful in applications where pre-assembled wiring harnesses are needed, helping reduce wiring errors and improve efficiency.
Quick Product Highlights
- 8-pole female connector with front-entry wiring
- Push-in CAGE CLAMP® for tool-free connections
- Supports 0.25 mm² to 4 mm² conductors
- Rated 690 V / 24 A
- 5.2 mm pin spacing; gray polyamide housing
- UL94 V-0 flame-retardant material
Get your WAGO 2022-108 1-Conductor Female Connector at Kinequip today.
