The WAGO 2604-3108 PCB Terminal Block is a compact, lever-operated connector designed for high-load applications. It supports up to 32 A and 400 V, making it ideal for demanding electrical environments. This model features eight clamping points across a single level, allowing connection of eight potentials. Its Push-in CAGE CLAMP® technology enables fast, tool-free wiring of solid and ferruled conductors. No crimping is needed, and conductors can be inserted directly.
The terminal block accepts wire sizes from 0.2 mm² to 4 mm² and requires a strip length between 9 mm and 11 mm. It mounts via through-hole soldering with 0.8 x 1 mm solder pins, each 4 mm long. The conductor entry is angled at 90°, and the pitch between pins is 5 mm. The housing is made of durable polyamide (PA66), with chrome-nickel spring steel clamps and tin-plated electrolytic copper contacts.
Its vertical orientation make it easy to integrate into board layouts. The lever mechanism simplifies maintenance and ensures secure connections without screws. This terminal block is RoHS compliant and built for long-term reliability.
Quick Product Highlights
- 8-pole, single-level terminal block
- Push-in CAGE CLAMP® with lever operation
- Rated for 400 V / 32 A
- Accepts 0.2–4 mm² conductors
- 5 mm pitch, through-hole mounting
- Durable PA66 housing, tin-plated copper contacts
- Tool-free wiring with 90° conductor entry
