The WAGO 2604-3302 PCB Terminal Block is a compact, 2-conductor solution designed for high-load applications. It supports conductor cross-sections from 0.2 mm² to 4 mm² and is rated for up to 1000 V and 32 A. This terminal block uses WAGO’s Push-in CAGE CLAMP® technology, allowing tool-free insertion of solid and ferruled conductors.
Its single-level design includes two clamping points on one level, enabling two potentials to be connected. The terminal block features a lever for easy operation and mounts at a 90° angle to the PCB using through-hole technology (THT). Solder pins measure 0.8 x 1 mm and are 4 mm long.
The housing is made of flame-retardant polyamide (PA66), and the contact surfaces are tin-coated electrolytic copper. The clamping spring is made of chrome-nickel spring steel, ensuring long-term durability. With dimensions of 14.9 mm x 25.3 mm x 16.7 mm, it fits neatly into compact PCB layouts.
Quick Product Highlights
- 2-conductor PCB terminal block with lever
- Push-in CAGE CLAMP® for tool-free wiring
- Rated 1000 V / 32 A
- Supports 0.2–4 mm² conductors
- Through-hole mount; 90° insertion angle
- Flame-retardant PA66 housing; tin-coated contacts
Get your WAGO 2604-3302 PCB Terminal Block at Kinequip today.
