The WAGO 734-112 12-Pole Female Connector is a compact terminal block designed for fast and reliable wiring. It uses WAGO’s CAGE CLAMP® technology, which allows you to connect solid or stranded wires without tools. This makes installation quicker and reduces the chance of wiring mistakes.
With 3.5 mm pin spacing and support for wire sizes from 0.08 mm² to 1.5 mm², this connector is ideal for tight spaces and multi-conductor setups. The 12-pole layout gives you flexibility for more complex wiring needs. Its free-hanging design and 180° wire entry make cable routing easier in crowded panels.
The housing is made from flame-retardant polyamide and includes retention latches for added stability. Tin-plated copper alloy contacts provide strong conductivity, while the spring clamp ensures consistent pressure on each wire. The connector is fully protected against mismating and supports coding options to prevent incorrect connections.
Rated for up to 10 A and 320 V, the 734-112 meets UL, CSA, and IEC standards. It’s a dependable choice for control panels, lighting systems, and industrial automation.
Quick Product Highlights
- CAGE CLAMP® for tool-free wiring
- 12-pole, 3.5 mm pin spacing
- Supports 0.08–1.5 mm² conductors
- Free-hanging with 180° wire entry
- Fully protected against mismating
Get your WAGO 734-112 12-Pole Female Connector at Kinequip today.
