The WAGO 745-304/005-000 PCB Terminal Block is a 4-pole, through-hole connector designed for secure wire-to-board connections in industrial and automation systems. It features WAGO’s CAGE CLAMP® spring pressure technology, allowing fast, tool-free termination of solid and stranded conductors. With a 7.5 mm pin spacing and a 45° angled mating orientation, this terminal block supports efficient layout and easy access in tight PCB configurations.
Each terminal accommodates wire sizes from 10 to 24 AWG, with a maximum current rating of 30 A and voltage capacity up to 300 V. The gray housing is made from flame-retardant polyamide (PA66), rated UL94 V0, and supports operating temperatures from -60°C to +105°C. The block includes a commoning option for simplified circuit design and is RoHS compliant.
Its compact footprint and angled design make it ideal for control panels, power distribution boards, and automation equipment. The 745-304/005-000 offers reliable performance, vibration-resistant connections, and long-term durability in demanding environments.
Quick Product Highlights
- 4-pole PCB terminal block with 7.5 mm pitch
- CAGE CLAMP® spring pressure connection
- Supports 10–24 AWG conductors
- Rated for 30 A / 300 V
- 45° angled mating orientation
- Flame-retardant PA66 housing (UL94 V0)
Get your WAGO 745-304/005-000 PCB Terminal Block at Kinequip today.
