The WAGO 788-506 Relay Socket is a compact relay module designed for DIN-rail mounting in industrial control systems. It features a single-pole changeover contact (SPDT) and operates with a nominal coil voltage of 24 VAC. With a continuous current rating of 16 A and a maximum switching voltage of 250 VAC, it’s ideal for general-purpose switching applications.
This relay includes a red LED status indicator for quick visual confirmation of operation. Its electromechanical design ensures reliable performance, while the spring terminal connection simplifies wiring and improves installation speed. The module’s slim 15 mm width saves space in control panels, and its gray housing is flame-retardant and built for durability.
The 788-506 supports a wide operating temperature range from -40°C to 70°C and features silver-nickel contacts for enhanced conductivity and longevity. It’s RoHS3 compliant and REACH affected, meeting modern environmental standards. Whether you’re automating machinery or managing power distribution, this relay socket offers dependable switching and easy integration.
Quick Product Highlights
- SPDT contact with 24 VAC coil
- Rated for 16 A, 250 VAC max
- Red LED status indicator
- DIN-rail mountable, 15 mm wide
- Spring terminal connections
Get your WAGO 788-506 Relay Socket at Kinequip today.
