CEJN 10-232-6434 | Female Nipple Coupling, 3/8" NPT
, , ,

CEJN 10-232-6434 | Female Nipple Coupling, 3/8″ NPT

SKU: 10-232-6434

$20.90

Request a Quote

CEJN 10-232-6434 | Female Nipple Coupling, 3/8″ NPT

Series 232 is a series of robust screw-to-connect couplings. The standard version is equipped with a ball type valve, but it is also available with poppet valve for considerably higher flow performance. These hydraulic couplings are compliant with ISO 14540 to ensure complete interchangeability with other brands following the same standard. High flow rate capacity, high quality and ability to withstand harsh conditions, make them an ideal fit for many different applications.

Category  | Nipples
Description Class  | Female thread
Connection  | 3/8″ NPT
Length  | 39 mm
Diameter  | 32 mm
Hexagon  | 24 mm
Rec. torque (Nm)  | 70-80 mm

Nominal flow diameter  | 10mm (0.4″)
Flow capacity  | Ball type: 21.2 l/min (4.7 GPM UK) Poppet type: 35 l/min (7.7 GPM UK)
Max. working pressure  | 72 MPa
Min. burst pressure connected  | 216.0 MPa
Min burst pressure coupling disconnected  | 185.0 MPa
Min burst pressure nipple disconnected  | 150.0 MPa
Temperature range  | -30°C — +100°C (-22°F — +212°F)
Material coupling  | Zinc plated steel
Material nipple  | Zinc plated steel
Material seal  | Nitrile NBR
